SUPERFINISHING ATTACHMENT MACHINES :

SUPERFINISHING HEAD

SPECIFICATION

MACHINE	SUPERFINISHING HEAD
MODEL NO	XLR-SF-100
SUPERFINISHING HEAD	OSCILLATING ROLLER TYPE WITH MECHANICAL OSCILLATION.
CONSUMABLE	MICROFINISHING FILM
ABRASIVE FILM SIZE	100 mm WIDTH
FILM FEED RATE	25 TO 250 mm/Min ADJUSTABLE.
BACKING PRESSURE	WITH PNEUMATIC CYLINDER ADJUSTABLE.
TOTAL CONNECTED LOAD	0.5 HP

APPLICATION	TO IMPROVE THE SURFACE FINISH
BENEFITS	RIGID & COMPACT DESIGN, VARIABLE OSCILLATION, VARIABLE FILM FEED RATE.
ACCESSORIES	COOLANT SYSTEM.
OPTIONS	COMPLETE MACHINES ARE AVAILABLE FOR PISTON ROD, CRANKSHAFT, CAM SHAFT, GRAVURE ROLLER DIFFERENT FILM WIDTH, SINGLE HEAD / MULTI HEAD / HEAVYDUTY TYPE MACHINES ARE AVAILABLE.

XLR-SF-100 (DC TYPE)

MODEL NO :	XLR-SF-100-DC

SPECIFICATION
Tape Width	20 - 100mm
Tape Speed	30 to 125 mm/min
Roller size	80 & 120 mm.
Roller Hardness	65 Shore A
Oscillation	3 mm
Oscillation Speed	Max 500 Osc/min
Voltage	220V AC
Weight	45 Kg
Size	Width 285 x Depth 500 x Height 425 (mm) + Control Panel
Electrical	With Control Panel
Air Pressure	5 Kg/cm2

APPLICATION	Microfinishing of shaft, rollers, piston rods

XLR – ADVANTAGE	Rigid & Compact Design, Variable oscillation, adjustable & accurate film feed rate thru electronic controller.

XLR – ACCESSORIES (ADDITIONAL COST)	COOLANT SYSTEM.

XLR – OTHER MACHINE OPTIONS	Superfinishing units are available in various widths as per applications.
